CW-Laser | Singlemode | Air Cooled
Discover the CW-Laser | Singlemode | Air-Cooled-Series - Compact, super lightweight and air-cooled CW fiber lasers with output power of up to 1200 Watt.
Specially developed for mobile systems, perfect for Laser Welding and Cutting.
They not only offer outstanding energy efficiency and excellent optical characteristics, but also maximum durability with minimum maintenance. The beam profile can be adapted to your laser process by selecting different fiber cores. For perfect process results.
Individual customizatios? No problem - we are here to support you!
Special Features:
Extra compact and lightweight design
No additional cooling required
Customizable fiber cores and lengths
Outstanding energy efficiency
Typical Laser Applications:
Welding
Structuring
Cutting
Cleaning
Typical Materials:
Stainless Steel
Aluminium
Titanium
Ceramics
Plastics
and more
CW-Laser | Singlemode | Air Cooled
| Model Name | Wavelength | Nominal Output Power CW | Beam Quality | Beam Parameter Product (BPP) (≤) | Modulation Frequency | Net Weight | Mechanical Dimensions Depth | Mechanical Dimensions Height | Mechanical Dimensions Width | Cooling Method | Inquiry | Detail |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CW-200SM-A | 1080 nm | 200 W | 1.5 <M² | 0.516 mm*mrad | 1 Hz - 4 kHz | 8.9 kg | 340 mm | 100 mm | 265 mm | Air | ||
| CW-300SM-A | 1080 nm | 300 W | 1.5 <M² | 0.516 mm*mrad | 1 Hz - 4 kHz | 8.9 kg | 340 mm | 100 mm | 265 mm | Air | ||
| CW-600SM-A | 1080 nm | 600 W | 0.47 mm*mrad / 0.5 mm*mrad | 1 Hz - 10 kHz | 15.5 kg | 365 mm | 122 mm | 383 mm | Air | |||
| CW-800SM-A | 1080 nm | 800 W | 0.47 mm*mrad / 0.5 mm*mrad | 1 Hz - 10 kHz | 15.5 kg | 365 mm | 122 mm | 383 mm | Air | |||
| CW-1200SM-A | 1080 nm | 1,200 W | 0.5 mm*mrad | 1 Hz - 10 kHz | 30.5 kg | 465 mm | 181.5 mm | 510 mm | Air |
